Working with Houdini and Hygraph

In this example, Scott Spence shows how to use Houdini, the disappearing GraphQL client, with your Hygraph and SvelteKit project.

Scott Spence
Working with hygraph, Houdini, Sapper, and GraphQL

Houdini: the disappearing GraphQL client!

In this post, we'll be taking a look at Houdini and how you could use it in your Hygraph projects.

Houdini was created to reduce the amount of boilerplate code needed to make GraphQL queries to an API. This reduces the overhead needed for building a SvelteKit project that uses GraphQL. We'll go into detail on this shortly, but first, let's take a look at some of the features you get with Houdini.

  • Composable and co-located data requirements for your components
  • Normalized cache with declarative updates
  • Generated types
  • Subscriptions
  • Support for SvelteKit and Sapper
  • Pagination (cursors and offsets)

(Feature list taken from the Houdini documentation)

Getting set up!Anchor

We'll be using the Hygraph starter blog template to get started here. You can quickly spin up this template from your Hygraph dashboard.

In these examples, I'll be using pnpm you can use npm or yarn if you prefer.

# create new svelte project named hygraph-with-houdini
pnpm init svelte@next hygraph-with-houdini
# change directory into the newly created project
cd hygraph-with-houdini
# install dependencies
pnpm install
# optional init git repo
git init && git add -A && git commit -m "Initial commit" (optional)

From the SvelteKit CLI options I'll be choosing:

Which Svelte app template? › Skeleton project
Use TypeScript? › No
Add ESLint for code linting? › No
Add Prettier for code formatting? › Yes

With the project initialized, I can add in the dependencies for Houdini as dev dependencies -D.

pnpm i -D houdini houdini-preprocess

Now that's installed, I can bootstrap the project with the Houdini init command.

npx houdini init

Here's where I'll be prompted for the project API, you can check out the video here for how to get that:

I'll paste in the content API URL and hit enter, I'll choose SvelteKit from the CLI prompt and I'll accept the default (./schema.graphql) for where the schema should be written to.

Svelte ConfigurationAnchor

There's a couple of options I'll need to add into the svelte.config.js file now so Vite (the tool used to build Svelte) can use Houdini in the project.

Here's what my svelte.config.js file looks like:

import adapter from '@sveltejs/adapter-auto'
import houdini from 'houdini-preprocess'
import path from 'path'
/** @type {import('@sveltejs/kit').Config} */
const config = {
preprocess: [houdini()],
kit: {
adapter: adapter(),
// hydrate the <div id="svelte"> element in src/app.html
target: '#svelte',
vite: {
resolve: {
alias: {
$houdini: path.resolve('.', '$houdini'),
},
},
server: {
fs: {
// Allow serving files from one level up to the project root
// https://vitejs.dev/config/#server-fs-allow
allow: ['..'],
},
},
},
},
}
export default config

Add Houdini ClientAnchor

Now to have the Houdini client available to the project, I'll need to add this to somewhere where it will be available to the whole project. The SvelteKit __layout file is a good place to add this.

I'll need to create the layout file, I'll do that with this bash one-liner:

touch src/routes/__layout.svelte

In the newly created __layout.svelte file, I'll add the following:

<script context="module">
import { setEnvironment } from '$houdini'
import environment from '../environment'
setEnvironment(environment)
</script>
<slot />

Optional stylingAnchor

I will just focus on how to use Houdini here, so I'll skip the styling. If you want to use Tailwind classes in the project, you can use the following to initialise the project to use Tailwind:

npx svelte-add@latest tailwindcss

Fetch the Hygraph API DataAnchor

I'm going to define the first GraphQL query for use in the project. This is the standard information you'd want to display on a blog landing page.

I'll pop in a <pre> tag with the posts object returned from the Houdini query so I can see the data on the page as a quick way to validate it's working.

<script>
import { graphql, query } from '$houdini'
const { data } = query(graphql`
query AllPosts {
posts {
title
slug
date
excerpt
tags
coverImage {
url(transformation: { image: { resize: { width: 400, height: 400, fit: clip } } })
}
}
}
`)
const { posts } = $data
</script>
<pre>{JSON.stringify(posts, null, 2)}</pre>

You may have noticed the $ on the data object, this is a Svelte store and the $ is how I can subscribe to it.

Now for Houdini to know about that query, I'll need to run the Houdini generate command:

npx houdini generate

This will throw an error, because Houdini needs to know how to handle the Date type:

npx houdini generate
AllPosts
Error: Could not convert scalar type: Date

There's a couple of issues on the Houdini GitHub repo detailing how to create a custom scalar type.

Here's what my houdini.config.js looks like now with the custom scalar added:

/** @type {import('houdini').ConfigFile} */
const config = {
schemaPath: './schema.graphql',
sourceGlob: 'src/**/*.svelte',
module: 'esm',
framework: 'kit',
scalars: {
// the name of the scalar we are configuring
Date: {
// the corresponding typescript type (what the typedef generator leaves behind in the response and operation inputs)
type: 'Date',
// turn the api's response into that type
unmarshal(val) {
const date = new Date(val).toISOString()
return date
},
// turn the value into something the API can use
marshal(date) {
return date.getTime()
},
},
},
}
export default config

If I try the Houdini generate command again, I'll get the following output:

npx houdini generate
AllPosts

Looks like there no issues there now!

As a side note here, I'll be adding in some more queries while building out this example, so what I'll do is add the npx houdini generate command to the project scripts.

This is so that I don't have to stop the dev server each time I add a new query to have Houdini generate the files needed.

Here's what the scripts look like in my package.json file now:

"scripts": {
"dev": "npx houdini generate && svelte-kit dev",
"build": "npx houdini generate && svelte-kit build",
"package": "svelte-kit package",
"preview": "npx houdini generate && svelte-kit preview",
"lint": "prettier --ignore-path .gitignore --check --plugin-search-dir=. .",
"format": "prettier --ignore-path .gitignore --write --plugin-search-dir=. ."
},

Ok, I'll run the dev script again now and check localhost:3000 in my browser to see the data I've added.

On the browser page, I get the following JSON data back from the Houdini query:

[
{
"title": "Technical SEO with Hygraph",
"slug": "technical-seo-with-hygraph",
"date": "2020-05-05T00:00:00.000Z",
"excerpt": "Get started with your SEO implementation when using a Headless CMS",
"tags": ["SEO"],
"coverImage": {
"url": "https://media.graphassets.com/resize=fit:clip,height:400,width:400/Ey8F3QcRzKVWqn9W7Pl7",
"id": "ckhz8xs9k1sv60952ql0sflru"
},
"id": "ckadrcx4g00pw01525c5d2e56"
},
{
"title": "Union Types and Sortable Relations with Hygraph",
"slug": "union-types-and-sortable-relations",
"date": "2020-05-01T00:00:00.000Z",
"excerpt": "Learn more about Polymorphic Relations and Sortable Relations with Hygraph",
"tags": ["Union Types"],
"coverImage": {
"url": "https://media.graphassets.com/resize=fit:clip,height:400,width:400/OUT7id5vT2XOaLEMAspU",
"id": "ckhz8z76w1rpy0a53x96s7wkd"
},
"id": "ckadrfuu000pe0148kels2b5e"
}
]

Now I have everything I need to build out the landing page.

Add Page MarkupAnchor

After the <script> tags, I'll use the Svelte Head API to give the page a title.

Some introductory text to explain what the page is about.

Then I'll use the Svelte {#each} directive to loop through the posts and display them on the page.

Here's what the file looks like now:

<script>
import { graphql, query } from '$houdini'
const { data } = query(graphql`
query AllPosts {
posts {
title
slug
date
excerpt
tags
coverImage {
url(
transformation: {
image: {
resize: { width: 400, height: 400, fit: clip }
}
}
)
}
}
}
`)
const { posts } = $data
</script>
<svelte:head>
<title>Houdini with Hygraph | Welcome</title>
</svelte:head>
<h1>Houdini with Hygraph</h1>
<p>
An example project using the Hygraph blog template and Houdini for
the GraphQL client
</p>
{#each posts as { title, slug, excerpt, coverImage, tags }}
<div>
<figure>
<img src={coverImage.url} alt={`Cover image for ${title}`} />
</figure>
<div>
<h2>{title}</h2>
<p>{excerpt}</p>
<div>
{#each tags as tag}
<span>{tag}</span>
{/each}
</div>
<div>
<a sveltekit:prefetch href={`/posts/${slug}`}>
Read &rArr;
</a>
</div>
</div>
</div>
{/each}

Now that the landing page information is on there, I have a list of clickable links to take me to the post for more detail.

That route doesn't exist yet so I'll create that now, again with a terminal command:

# make the posts directory
mkdir src/routes/posts
# make the [slug].svelte file
touch src/routes/posts/'[slug]'.svelte

Now I'll need a way to get the slug from the URL into the PostQuery in the src/routes/posts/[slug].svelte file.

Using Query VariablesAnchor

So the query for the post page will need to take a query parameter (slug) and use that to get the post.

The query will look something like this, I've taken out the author and cover image fields for brevity:

query PostQuery($slug: String!) {
post(where: { slug: $slug }) {
title
date
tags
content {
html
}
}
}

I can use that query much the same way I did it on the index page, following the same pattern.

<script>
import { graphql, query } from '$houdini'
const { data } = query(
graphql`
query PostQuery($slug: String!) {
post(where: { slug: $slug }) {
title
date
tags
# author
content {
html
}
# coverImage
}
}
`
)
const { post } = $data
</script>
<pre>{JSON.stringify(post, null, 2)}</pre>

Here's where things get a bit specific to Houdini, as Houdini replaces the load function in SvelteKit with a Variables function. It takes the same arguments as the load function, so this is where I can destructure out the params object to get the slug that can be used in the query.

I'll add this to the top of the file:

<script context="module">
export const PostQueryVariables = ({ params }) => {
const { slug } = params
return {
slug,
}
}
</script>

One thing to note is that the Variables function will take on the name of the query defined, so on this file the query is PostQuery so the load function for the page needs to be PostQueryVariables.

Add [slug] Page MarkupAnchor

Now, I can add in the markup needed to display the post.

Here's what my src/routes/posts/[slug].svelte file looks like now:

<script context="module">
export const PostQueryVariables = ({ params }) => {
const { slug } = params
return {
slug,
}
}
</script>
<script>
import { graphql, query } from '$houdini'
const { data } = query(
graphql`
query PostQuery($slug: String!) {
post(where: { slug: $slug }) {
title
date
tags
author {
name
authorTitle: title
picture {
url(transformation: { image: { resize: { fit: clip, height: 50, width: 50 } } })
}
}
content {
html
}
coverImage {
url
}
}
}
`
)
const { post } = $data
const {
title,
coverImage,
author: { picture, name, authorTitle },
date,
tags,
content: { html },
} = post
</script>
<svelte:head>
<title>Houdini with Hygraph | {title}</title>
</svelte:head>
<img src="{coverImage.url}" alt="{`Cover" image for ${title}`} />
<h1>{title}</h1>
<a href="/" class="inline-flex items-center mb-3">
<img src="{picture.url}" alt="{name}" />
<span>{name}</span>
<span>{authorTitle}</span>
</a>
<p>{new Date(date).toDateString()}</p>
{#if tags} {#each tags as tag}
<span>{tag}</span>
{/each} {/if}
<article>{@html html}</article>

FinAnchor

That's it! I've created a simple blog template using Hygraph and Houdini.

I hope you found it useful.
